Overview
This 304 stainless steel spiral wound gasket is engineered for high-pressure flange connections in industrial piping systems. Its robust construction combines a spirally wound metal outer windings with a resilient graphite filler, creating a seal capable of handling significant pressure fluctuations and thermal cycling. Designed for indoor process environments, it provides a reliable, long-lasting seal for critical piping infrastructure where leak prevention is paramount.
Key Features
Constructed with 304 stainless steel outer windings for corrosion resistance
Features a resilient graphite filler for superior thermal and chemical compatibility
Engineered spiral wound design provides excellent recovery and sealing under bolt load Conforms to established HG/T industry standards for dimensional consistency and performance Suitable for a wide range of pressure classes, offering versatile application coverage
Specifications
Standards: HG Chemical Base: Graphite Sealant Type: Spiral Wound Gasket Indoor/Outdoor Use: Indoor Paintable: No Nominal Size: 14.5 inches x 14.3 inches Thickness: 1/8 inch Pressure Rating: PN16, PN25, PN40, PN63, PN100, PN160 Metal Component: 304 Stainless Steel Filler Material: Graphite Package Quantity: 6 gaskets
Applications
Sealing high-pressure flanges in chemical and petrochemical processing plants
Connections in power generation and utility piping systems
Industrial HVAC and process heating lines General industrial fluid handling systems requiring a dependable, reusable seal
