Overview
This 14-inch spiral wound gasket is engineered for high-pressure, high-integrity sealing in critical industrial piping systems. Designed to meet the demands of PN100 (Class 600) flange ratings, it provides a robust and reliable seal capable of withstanding significant mechanical stress and thermal cycling. The gasket's construction combines the strength of metal with the sealing properties of a non-metallic filler, creating an optimal balance for challenging applications in chemical processing, power generation, and oil and gas operations.
Key Features
Engineered for PN100/Class 600 high-pressure service Constructed with corrosion-resistant 304 stainless steel windings Features a polytetrafluoroethylene (PTFE) filler for chemical inertness
Includes an outer centering ring for precise and secure flange alignment
Provides excellent resilience and recovery under bolt load
Suitable for use in both indoor and outdoor environments
Delivers reliable sealing across a wide range of temperatures and pressures
Specifications
Nominal Pipe Size: 14 inches Pressure Rating: PN100 (Approximately 1440 PSI) Construction: Spiral Wound Metal Windings: 304 Stainless Steel Filler Material: Polytetrafluoroethylene (PTFE) Outer Ring: 304 Stainless Steel Centering Ring Standards: Meets Industry Standards Sealant Type: Gasket Indoor/Outdoor Use: Both Paintable: No Pack Size: 1 unit
Applications
Ideal for sealing flanges in high-pressure piping systems within chemical and petrochemical plants Suitable for heat exchangers, pumps, valves, and vessel connections in power generation facilities Used in oil and gas production, transmission, and refining operations
Applicable for processes handling aggressive chemicals where PTFE compatibility is required Effective for general industrial maintenance and repair on Class 600 flanges
