Overview
This 5-inch nominal diameter spiral wound gasket is engineered for creating reliable, leak-tight seals in industrial flanged connections. It is specifically constructed to handle demanding service conditions, including thermal cycling and pressure fluctuations up to 125 PSI. The gasket's robust design conforms to common industry dimensional standards, ensuring compatibility and predictable performance in a wide array of piping and vessel applications.
Key Features
Core winding constructed from durable 316 stainless steel for high strength and corrosion resistance Filler material of pure PTFE (polytetrafluoroethylene) fluoropolymer for broad chemical compatibility
Spiral wound design provides inherent resilience and excellent sealing under bolt load
Suitable for use in both indoor and outdoor installations
Engineered to withstand thermal and pressure cycling without compromising seal integrity
Specifications
Sealant Type: Spiral Wound Gasket Nominal Pipe Size: 5 inches Pressure Rating: 125 PSI Construction: 316 Stainless Steel Windings with PTFE Filler Outer Diameter: Approximately 7.56 inches Inner Diameter: Approximately 5.55 inches Overall Thickness: 0.126 inches Standards: Manufactured to Common Industry Specifications Chemical Base: Fluoropolymer (PTFE) Indoor/Outdoor Use: Suitable for Both Paintable: No Package Quantity: 12 Gaskets
Applications
Sealing flanged joints in chemical and petrochemical processing pipelines
General service in oil and gas production and refining equipment
Use in power generation facilities for utility and process lines Compatible applications in pharmaceutical, food, and beverage processing where chemical resistance is required General industrial plant maintenance for pumps, valves, and heat exchangers
