Overview
The Metal C-Ring Gasket is a precision-engineered sealing solution designed for high-integrity flange connections in demanding industrial piping systems. It is constructed to maintain a leak-free seal under significant pressure and temperature fluctuations, ensuring reliability in critical process environments. This gasket is manufactured to recognized industry standards, providing a trusted component for maintenance and new installation projects.
Key Features
Robust C-ring wound construction for superior sealing performance 304 stainless steel inner and outer rings for corrosion resistance and structural integrity
Flexible graphite filler that adapts to flange face imperfections Engineered for high-pressure applications up to 360 PSI (PN25)
Excellent resistance to thermal cycling and creep relaxation
Suitable for repeated use in systems requiring dependable disassembly and reassembly
Specifications
Type: Metal C-Ring / Wound Gasket Nominal Size: DN40 Outside Diameter: 4.5 inches Inside Diameter: 3.6 inches Thickness: 0.18 inches Pressure Rating: PN25 (360 PSI) Metal Ring Material: 304 Stainless Steel Filler Material: Flexible Graphite Industry Standard: HG/T20610-2009 Chemical Base: Graphite Sealant Type: Gasket Intended Use: Indoor Paintable: No Package Quantity: 12 pieces
Applications
This gasket is specified for sealing flanges in chemical and petrochemical processing Ideal for high-temperature and high-pressure steam lines
Suitable for oil and gas pipeline connections and valve bonnets
Used in power generation and industrial plant maintenance Applicable for any piping system requiring a conformable, resilient seal for flat face flanges
