Overview
This 12-inch flange gasket is engineered for critical sealing in high-pressure and high-temperature piping systems. It is a metal wound gasket of the C-shape style with an outer centering ring, constructed from corrosion-resistant 316L stainless steel windings filled with a flexible graphite layer. This design creates a robust, pressure-adaptive seal ideal for raised face flanges in demanding process applications, including chemical processing, power generation, and oil and gas operations. Each unit is manufactured to precise industry dimensional standards to ensure proper fit and performance.
Key Features
Constructed with 316L stainless steel for superior corrosion resistance
Flexible graphite filler provides excellent thermal conductivity and seal resilience Metal wound C-shape design allows for compression and recovery under load Integrated outer ring ensures easy alignment on flanges and prevents over-compression Rated for service in pressure classes up to 150 lbs
Suitable for a wide range of media and extreme temperature services
Specifications
Material: 316L Stainless Steel with Graphite Filler Nominal Size: 12 inch Pressure Class: 150 lbs Construction: Metal Wound, C-Shape with Outer Ring Standards: Manufactured to Industry Standard Dimensions Connection Type: For Use with Raised Face Flanges Package Quantity: 2 Gaskets
Applications
Sealing pipe flanges in chemical and petrochemical plants High-temperature steam lines in power generation facilities
Process piping in oil and gas refineries General industrial service for aggressive or volatile media
