Overview
This high-performance stainless steel flange gasket is engineered for critical sealing in high-pressure and high-temperature piping systems. It utilizes a robust C-shaped metal winding construction with an outer centering ring, providing exceptional seal integrity and resistance to gasket blow-out. Manufactured to precise industry standards, it ensures reliable performance and dimensional compatibility in demanding industrial applications, including chemical processing, power generation, and oil and gas operations.
Key Features
C-shaped wound metal design with an outer ring for enhanced stability Rated for pressure conditions up to PN63 (approximately 914 PSI) Constructed from corrosion-resistant 304 stainless steel windings
Graphite filler provides superior thermal conductivity and resilience
Outer ring ensures proper alignment and prevents crushing
Suitable for a wide range of temperatures and media
Specifications
Material: 304 Stainless Steel windings and outer ring with Graphite filler Nominal Diameter (DN): 32 (1.93 inches) Pressure Rating: PN63 (Approx. 914 PSI) Design Standard: Compliant with Industry Flange Gasket Specifications Construction: Metal Wound with Outer Ring Package Quantity: 25 pieces
Applications
Sealing flanges in high-pressure steam lines
Chemical and petrochemical processing pipelines
Power plant boiler feed and turbine systems
Compressed air and industrial gas lines
Refinery and hydrocarbon service connections General industrial piping requiring a robust, reliable seal
